(1) choke lever (A) fully ON
(B) detent position
(C) fully OFF
(1)
29
Starting Procedure
Preparation
Starting & Stopping the Engine
Basic Operation & Riding
High Air Temperature.
To restart a warm engine, follow the procedure
for
Normal Air Temperature
10° 35°C (50° 95°F)
Your motorcycle can be kickstarted with the
transmission in gear by pulling in the clutch
lever before operating the kickstarter.
Always follow the proper starting procedure
described below.
Make sure that the transmission is in neutral.
Turn the fuel valve ON.
Pull the choke lever ( ) up all the way to
fully ON ( ).
(cont’d)
1.
1
A
03/05/20 10:00:26 31KCY680_038

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda 2004 XR400R and is the answer not in the manual?

Honda 2004 XR400R Specifications

General IconGeneral
Displacement397 cc
Cooling SystemAir-cooled
Bore x Stroke85.0 mm x 70.0 mm
Compression Ratio9.3:1
Transmission5-speed
Front BrakeSingle disc
Rear BrakeSingle disc
IgnitionCDI
Front Tire80/100-21
Rear Tire110/100-18
Engine TypeAir-cooled 4-stroke single cylinder
Front Suspension43mm telescopic fork
Rear SuspensionPro-Link single shock
InductionCarburetor
Ground Clearance12.4 inches
