4 of 6 All 37152 (0706) © 2007 American Honda Motor Co., Inc. - All Rights Reserved.
5715030Y
SELF-TAPPING SCREW
(Removed in step 11.)
5 x 8 mm
WASHER
SCREW
(Included
with the
player.)
5 x 8 mm
WASHER
SCREW
(Included with
the player.)
HEATER
CONTROL
UNIT
DIN BEZEL
SELF-
TAPPING
SCREWS
LEFT VEHICLE
BRACKET
(not reused)
HEATER
CONTROL UNIT
POCKET
RIGHT
VEHICLE
BRACKET
(not reused)
SELF-
TAPPING
SCREWS
SELF-
TAPPING
SCREWS
(Reuse.)
SELF-
TAPPING
SCREWS
(Reuse.)
SELF-
TAPPING
SCREW
(Removed
in step 11.)
RIGHT
PLAYER
BRACKET
LEFT PLAYER
BRACKET
PLAYER
5426240Y
BUS
CABLE
VEHICLE
HARNESS
WIRE TIE
BUS CABLE
14-PIN
CONNECTOR
TO AUDIO UNIT
AUDIO
PANEL
OPENING
HEATER
CONTROL
UNIT
OPENING
30 mm
self-tapping screws), and separate the heater
control unit from pocket. Set the pocket aside, it
will not be reused.
12. Install the DIN bezel to the player. Set the heater
control unit on the player, and attach the left and
right player brackets to the player and the heater
control unit using the two self-tapping screws
removed in step 11 and four 5 x 8 mm washer-
screws included with the player.
Installing the Player
13. Route the bus cable from the audio panel opening
to the heater control unit opening. Using one wire
tie, secure the bus cable to the vehicle harness.
14. Connect the bus cable 14-pin connector to the
RIGHT
VEHICLE
BRACKET
SCREWS
HEATER
CONTROL UNIT
POCKET
LEFT
VEHICLE
BRACKET
VEHICLE 30-PIN
CONNECTOR
VEHICLE 20-PIN
CONNECTOR
vehicle brackets. Pull the heater control unit and
pocket out toward you, and unplug the vehicle
connectors.
11. Remove the left and right vehicle brackets (six
To Next Page
