Honda Africa Twin 2016 User Manual

142
Troubleshooting
Other Warning Indications
Fuel Gauge Failure Indication
If the fuel system has an error, the fuel gauge
indicators will be displayed as shown in the
illustration.
If this occurs, see your dealer as soon as
possible.
Coolant Temperature Gauge
Failure Indication
If the cooling system has an error, all
segments will blink or go off as shown in the
illustration.
If this occurs, see your dealer as soon as
possible.

Honda Africa Twin 2016 Specifications

General

Displacement	998cc
Bore x Stroke	92.0 mm x 75.1 mm
Compression Ratio	10.0:1
Max Torque	98 Nm @ 6, 000 rpm
Fuel System	PGM-FI electronic fuel injection
Front Tire	90/90-21
Rear Tire	150/70-18
Seat Height	870mm / 850mm (adjustable)
Fuel Tank Capacity	18.8 liters
Wheelbase	1, 575mm
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel-twin
Max Power Output	70 kW (95 hp) @ 7, 500 rpm
Transmission	6-speed manual
Frame Type	Steel semi-double cradle type
Front Suspension	45mm inverted telescopic fork, 230mm travel
Rear Suspension	Pro-Link with gas-charged damper, 220mm travel
Front Brake	310mm dual hydraulic disc with ABS
Rear Brake	256mm hydraulic disc with ABS
Curb Weight	228kg
