Honda Africa Twin 2018 User Manual

2. Make sure that the slot on the brake
caliper bracket is positioned in the lug on
the swingarm.
3. Adjust the drive chain. 2 P. 130
4. Install and tighten the rear axle nut.
Torque: 74 lbf·ft (100 N·m, 10.2 kgf·m)
5. Install the chain cover and tighten bolts.
6. Remove the protective tape or cloth.
7. After installing the wheel, apply the brake
pedal several times, then check if the
wheel rotates freely. Recheck the wheel if
the brake drags or if the wheel does not
rotate freely.
If a torque wrench was not used for
installation, see your dealer as soon as
possible to verify proper assembly.
Improper assembly may lead to loss of
braking capacity.
Tire Puncture u Removing Wheels
Troubleshooting
165
Lug
Swingarm
Brake caliper bracket
Slot

Honda Africa Twin 2018 Specifications

General

Displacement	998cc
Bore x Stroke	92.0mm x 75.1mm
Compression Ratio	10.0:1
Transmission	6-speed manual
Fuel System	PGM-FI electronic fuel injection
Fuel Tank Capacity	18.8 liters
Front Tire	90/90-21
Rear Tire	150/70-18
Wheelbase	1, 575mm
Ground Clearance	250mm
Engine Type	Liquid-cooled parallel twin
Max Power Output	70kW (94 hp) @ 7, 500 rpm
Max Torque	98Nm @ 6, 000 rpm
Seat Height	850mm (adjustable to 870mm)
Curb Weight	242 kg (DCT)
Front Suspension	Showa 45mm cartridge-type inverted telescopic fork with hydraulic dial-style preload adjuster
Rear Suspension	Pro-Link with adjustable preload and rebound damping
Front Brake	Dual 310mm wave floating hydraulic disc with 4-piston calipers
Rear Brake	256mm wave hydraulic disc with 2-piston caliper
Length	2, 335mm
Height	1, 475mm
