Honda Africa Twin CRF1100A 2022 User Manual

310
Troubleshooting
Warning Indicators On or Flashing
Low Oil Pressure Indicator
If the low oil pressure indicator comes on, pull
safely to the side of the road and stop the
engine.
1. Check the engine oil level, and add oil as
necessary. 2 P. 277, 2 P. 278
2. Start the engine.
u Only continue riding if the low oil pressure
indicator goes off.
Rapid acceleration may momentarily cause the
low oil pressure indicator to come on, especially
if the oil is at or near the low level.
If the low oil pressure indicator stays on when the
oil level is at the proper level, stop the engine
and contact your dealer.
If the engine oil level goes down rapidly, your
vehicle may have a leak or another serious
problem. Have your vehicle inspected by your
dealer.
PGM-FI (Programmed Fuel
Injection) Malfunction
Indicator Lamp (MIL)
If the indicator comes on while riding, you may
have a serious problem with the PGM-FI system.
Reduce speed and have your vehicle inspected
by your dealer as soon as possible.
NOTICE
Continuing to ride with low oil pressure can cause serious
damage to the engine.

Honda Africa Twin CRF1100A 2022 Specifications

General

Displacement	1084 cc
Bore x Stroke	92 mm x 81.5 mm
Compression Ratio	10.1:1
Transmission	6-speed manual
Fuel System	PGM-FI electronic fuel injection
Front Tire	90/90-21
Rear Tire	150/70-18
Engine Type	Liquid-cooled parallel twin
Max Power Output	75 kW
Power	73 kW (100.8 HP) @ 7, 500 rpm
Max Torque	105 Nm
Torque	105 Nm
Fuel Tank Capacity	18.8 liters (4.9 gallons)
Front Suspension	45 mm Showa
Rear Suspension	Pro-Link, adjustable
Front Brakes	Dual 310 mm
Rear Brakes	Single 256 mm disc with 1-piston caliper
Length	2, 330 mm (91.7 in)
Width	960 mm (37.8 in)
Height	1395mm (54.9 inches)
Wheelbase	1, 575 mm
Seat Height	850 mm
Weight	238 kg
