Warning Information
Indication Explanation Remedy
When the oil pressure
in the engine is low.
Refer to “Low Oil
Pressure Indicator”
(P.147)
When the coolant
temperature becomes
high.
Refer to “Overheating”
(P.146)
You can hide the pop-up information by pushing either the sel switch while the
pop-up information is displayed.
Operation Guide
73
Continued
Low oil pressure
indicator
Warning indicator
High coolant
temperature indicator
Warning indicator
