Honda CB500X 2020 User Manual

Specifications
■ Main Components
Overall length 84.8 in (2,155 mm)
Overall width 32.5 in (825 mm)
Overall height
Low 55.5 in (1,410 mm)
High 56.9 in (1,445 mm)
Wheelbase 56.9 in (1,445 mm)
Minimum ground
clearance
7.1 in (180 mm)
Caster angle 27.5°
Trail 4.3 in (108 mm)
Curb weight
CB500X 430 lb (195 kg)
CB500XA 434 lb (197 kg)
Maximum weight
capacity
*1
386 lb (175 kg)
Passenger capacity Rider and 1 passenger
Minimum turning radius 7.9 ft (2.40 m)
Displacement 28.7 cu-in (471 cm
3
)
Bore x stroke
2.64 x 2.63 in (67.0 x 66.8 mm)
Compression ratio 10.7:1
Fuel
Unleaded gasoline
Recommended: 86 PON or higher
Tank capacity 4.62 US gal (17.5 L)
Battery
YTZ8V
12 V- 7.0 Ah (10 HR)
Gear ratio
1st 3.285
2nd 2.105
3rd 1.600
4th 1.300
5th 1.150
6th 1.043
Reduction ratio
(primary / final)
2.029 / 2.733
*1 : Including rider, passenger, all luggage, and accessories
Specifications
152

Honda CB500X 2020 Specifications

General

Bore x Stroke	67mm x 66.8mm
Compression Ratio	10.7:1
Ignition	Computer-controlled digital transistorized with electronic advance
Transmission	6-speed
Final Drive	Chain
Rear Brake	Single 240mm disc
Front Tire	110/80-19
Rear Tire	160/60-17
Rake (Caster Angle)	27.5°
Starter	Electric
Engine Type	Liquid-cooled parallel-twin
Induction	PGM-FI fuel injection
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Brake	Single 310mm disc
Trail	4.3 inches
Seat Height	830mm (32.7 inches)
Fuel Capacity	4.6 gallons
Max Power Output	47 hp @ 8, 600 rpm
Width	825mm (32.5 inches)
Fuel Capacity (liters)	17.5 liters
Max Torque	31.7 lb-ft @ 6, 500 rpm
Wheelbase (mm)	1445
