General| Engine Type | 599cc liquid-cooled inline four-cylinder |
|---|---|
| Compression Ratio | 12.0:1 |
| Ignition | Computer-controlled digital transistorized with electronic advance |
| Transmission | 6-speed |
| Final Drive | O-ring-sealed chain |
| Rear Suspension | Single shock with adjustable preload |
| Rear Brakes | Single 240mm disc with single-piston caliper |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
| Fuel System | PGM-FI with automatic enrichment circuit |
| Front Suspension | 41mm inverted fork |
| Front Brakes | Dual 296 mm discs with 4-piston calipers |
| Rake | 25° |
| Seat Height | 800 mm |
| Power | 102 hp @ 12, 000 rpm |
| Torque | 47.9 lb-ft @ 10, 500 rpm |
| Width | 29.1 inches |
| Bore and Stroke | 67mm x 42.5mm |
| Wheelbase | 1, 440 mm |
