Honda CB650RA 2020 - User Manual

Questions and Answers

W
William RiveraAug 5, 2025
What to do if the starter motor operates but Honda CB650RA 2020 engine does not start?
- E
  Eric PowellAug 5, 2025
  If the starter motor operates, but the engine doesn't start, begin by verifying the engine starting procedure is correct. Ensure there's gasoline in the fuel tank and the engine stop switch is in the ON position. Check the PGM-FI malfunction indicator lamp (MIL). If it's illuminated, contact your dealer immediately. Also, inspect the battery connections for looseness or corrosion, and assess the battery's condition. If the issue persists, seek professional inspection from your dealer.
J
Juan JacksonAug 10, 2025
What to do if the low oil pressure indicator comes on in my Honda Motorcycle?
- A
  Anna CraigAug 10, 2025
  If the low oil pressure indicator illuminates, safely pull over to the side of the road and stop the engine. Check the engine oil level and add oil if necessary. If the oil level decreases rapidly, it could indicate a leak or another serious issue, so it's recommended to have your vehicle inspected by your dealer. You should only continue riding if the low oil pressure indicator turns off. If the indicator remains on even with the correct oil level, stop the engine and contact your dealer.
T
Teresa ScottAug 13, 2025
What to do if the engine is overheating on my Honda Motorcycle?
- J
  jcunninghamAug 14, 2025
  If the engine is overheating and the segment H flashes in the coolant temperature gauge, check that the radiator fan is operating, and then turn the ignition switch to the OFF position. If the fan isn't working, suspect a fault and transport your vehicle to your dealer without starting the engine. Allow the engine to cool down with the ignition switch off. Once cooled, inspect the radiator hose for leaks. If a leak is found, do not start the engine and transport your vehicle to your dealer. Also, check the coolant level in the reserve tank and add coolant if needed.
T
Thomas DixonAug 18, 2025
How to fix a dead battery on a Honda CB650RA 2020?
- M
  Mrs. Rebecca WrightAug 18, 2025
  To address a dead battery, charge it using a motorcycle battery charger. Remove the battery from the vehicle before charging. Avoid using an automobile-type battery charger, as it can cause overheating and permanent damage to the motorcycle battery. If the battery doesn't recover after recharging, contact your dealer.
J
jbarberAug 22, 2025
What happens if the ABS indicator stays on in my Honda CB650RA 2020 Motorcycle?
- L
  lindsey06Aug 22, 2025
  If the ABS indicator stays on, your brakes will function as a conventional system, but the anti-lock function will be disabled. If the indicator operates in one of the following ways, you may have a serious problem with the ABS. Reduce your speed and have your vehicle inspected by your dealer as soon as possible. Also, the ABS indicator may flash if you turn the rear wheel while it's lifted. If this happens, turn the ignition switch off and then on again. The ABS indicator should turn off once your speed reaches 19 mph (30 km/h).
T
Tracy AndersonAug 27, 2025
What happens if the torque control indicator is on in my Honda CB650RA 2020?
- B
  bburtonAug 27, 2025
  If the Torque Control indicator is on, your vehicle will have normal riding ability without the Torque Control function. If the indicator operates in one of the following ways, you may have a serious problem with the Torque Control. Reduce your speed and have your vehicle inspected by your dealer as soon as possible. When the indicator comes on while the Torque Control is active, completely close the throttle to regain normal riding ability. The Torque Control indicator may also appear if you rotate the rear wheel while the vehicle is lifted. In this case, turn the ignition off, then on again. The indicator should then turn off after reaching a speed of 3 mph (5 km/h).
F
franklin28Aug 31, 2025
How to replace a blown fuse on a Honda Motorcycle?
- M
  Mary RollinsAug 31, 2025
  To replace a blown fuse, first, consult the section on “Inspecting and Replacing Fuses.” Open the fuse box covers. Use the fuse puller from the tool kit to remove the fuses one by one and check for blown fuses. Always replace a blown fuse with a spare fuse of the same rating. After replacing the fuse, close the fuse box covers and reinstall the front seat. If a fuse repeatedly fails, it indicates an electrical problem, and you should have your vehicle inspected by your dealer.

Summary

Vehicle Safety

Safety Guidelines

Core safety practices for riding, including inspections and proper procedures.

Safety Precautions

Essential safety measures to take before and during riding, covering apparel and general conduct.

Riding Precautions

Specific advice for safe operation and handling, including break-in, brakes, and ABS.

Instruments

Speedometer

Displays the vehicle's current speed in mph or km/h.

Tachometer

Indicates engine revolutions per minute (RPM) via a bar segment.

Section A Display

Section B Display

Coolant Temperature Gauge

Monitors engine coolant temperature; segment H flashes if overheating.

Fuel Gauge

Current Fuel Mileage

Average Fuel Mileage

Fuel Consumption

Numerical Tachometer

Indicators

Torque Control Indicators

REV Indicator

Signals when engine RPM reaches preset shift-up points.

Switches

Engine Stop Switch

Torque Control Switch

Ignition Switch

Controls electrical system power and steering lock.

Honda Selectable Torque Control

Starting the Engine

Engine Start Procedure

Step-by-step guide to starting the engine correctly.

Engine Does Not Start

Troubleshooting steps if the engine fails to start.

Refueling

Refueling and Fuel Guidelines

Procedures and warnings for safely adding fuel to the tank.

Maintenance

Importance of Maintenance

Explains why regular maintenance is crucial for safety and performance.

Maintenance Schedule

Outlines required maintenance tasks and intervals.

Maintenance Safety

Guidelines and precautions for performing maintenance tasks safely.

Maintenance Fundamentals

General principles and safety for performing maintenance.

Engine Oil

Checking, adding, and changing engine oil and filter.

Coolant

Brakes

Inspecting brake fluid and pads, adjusting brake light switch.

Drive Chain

Clutch

Troubleshooting

Engine Will Not Start

Diagnoses and solutions for starting issues.

Overheating

Addresses issues when the coolant temperature gauge indicates overheating.

Warning Indicators On or Flashing

Explains the meaning of various warning lights and indicators.

Other Warning Indications

Tire Puncture

Guidance on emergency repairs and wheel removal for punctures.

Electrical Trouble

Troubleshooting for dead batteries, burnt bulbs, and blown fuses.

Warning Indicators On or Flashing

Low Oil Pressure Indicator

Warns when engine oil pressure is critically low.

PGM-FI Malfunction Indicator Lamp (MIL)

Indicates a problem with the fuel injection system.

ABS Indicator

Alerts to issues with the Anti-lock Brake System.

Torque Control Indicator

Tire Puncture

Emergency Repair Using a Tire Repair Kit

Instructions for minor tire repairs with a kit.

Removing Wheels

Electrical Trouble

Battery Goes Dead

Steps for charging a dead battery and troubleshooting.

Blown Fuse

Information

Instruments, Controls, & Other Features

Emission Control Systems

Catalytic Converter

Warranty Coverage and Service

Explains warranty terms, coverage, and service procedures.

Specifications

Service Data

Technical details for tires, fluids, spark plugs, and chain.

Torque Specifications

Honda CB650RA 2020 Specifications

General

Bore x Stroke	67.0 mm x 46.0 mm
Compression Ratio	11.6:1
Power	94 hp (70 kW) @ 12, 000 rpm
Fuel System	PGM-FI electronic fuel injection
Ignition System	Computer-controlled digital transistorized with electronic advance
Starter	Electric
Transmission	6-speed
Final Drive	Chain
Front Suspension	41 mm telescopic fork
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	810 mm (31.9 in)
Wheelbase	1, 450 mm (57.1 in)
Ground Clearance	150 mm (5.9 in)
Torque	64 Nm (47 lb-ft) @ 8, 500 rpm
Rear Brakes	Single 240 mm disc
Fuel Capacity	15.4 L (4.1 US gal)
Width	775 mm (30.5 in)
Engine Type	Liquid-cooled inline four-cylinder
Rear Suspension	Single shock with adjustable preload
Front Brakes	Dual 320 mm discs
