GENERAL INFORMATION
1-4
GENERAL SPECIFICATIONS
ITEM SPECIFICATION
DIMENSIONS Overall length 2,090 mm (82.3 in)
Overall width 750 mm (29.5 in)
Overall height 1,095 mm (43.1 in)
Wheelbase 1,340 mm (52.7 in)
Seat height 790 mm (31.1 in)
Footpeg height 567 mm (22.3 in)
Ground clearance 168 mm (6.6 in)
Dry weight 126 kg (278 lbs)
Curb weight 139 kg (306 lbs)
Maximum weight capacity 170 kg (375 lbs)
FRAME Frame type Diamond type
Front suspension Telescopic fork
Front wheel travel 130 mm (5.1 in)
Rear suspension Swingarm
Rear wheel travel 101 mm (4.0 in)
Rear damper One side operation
Front tire size 2.75-18 42P
Rear tire size 3.00-18 52P
Front tire brand MRF NYLOGRIP ZAPPER - FS
Rear tire brand MRF NYLOGRIP ZAPPER
Front brake Hydraulic single disc
Rear brake Mechanical drum (leading-trailing)
Caster angle 26° 00’
Trail length 97 mm (3.8 in)
Fuel tank capacity 13.0 liter (3.43 US gal, 2.86 lmp gal)
Fuel tank reserve capacity 1.0 liter (0.26 US gal, 0.22 lmp gal)
ENGINE Cylinder arrangement Single cylinder inclined 17° from vertical
Bore and stroke 57.3 x 57.8 mm (2.26 x 2.28 in)
Displacement 149.2 cm
3
(9.10 cu-in)
Compression ratio 9.1:1
Valve train Chain driven OHC with rocker arm
Intake valve opens at 1 mm (0.04 in) lift 7° BTDC
closes at 1 mm (0.04 in) lift 28° ABDC
Exhaust valve opens at 1 mm (0.04 in) lift 27° BBDC
closes at 1 mm (0.04 in) lift 3° ATDC
Lubrication system Forced pressure and wet pump
Oil pump type Trochoid
Cooling system Air cooled
Air filtration Paper filter
Engine dry weight 27.2 kg (60.0 lbs)
CARBURETOR Carburetor type Horizontal changable venturi
Throttle bore 26 mm (1.02 in)
DRIVE TRAIN Clutch system Multi-plate, wet
Clutch operation system Cable operating
Transmission 5 speeds
Primary reduction 3.350 (67/20)
Final reduction 2.800 (42/15)
Gear ratio 1st 3.076 (40/13)
2nd 1.789 (34/19)
3rd 1.304 (30/23)
4th 1.090 (24/22)
5th 0.937 (30/32)
Gearshift pattern Left foot operated return system
1 - N - 2 - 3 - 4 - 5
ELECTRICAL Ignition system DC – CDI
Starting system Kickstarter
Charging system Single phase output alternator
Regulator/rectifier SCR shorted, single phase half-wave recti-
fication
