Honda CRF230F 2004 User Manual

141
Taking Care of the Unexpected
Taking Care of the Unexpected
If Your Battery Is Low (or Dead)
Jump starting is not recommended, especially if
you use an automobile battery. The greater
amperage of an automobile battery when the
car engine is running can damage your
motorcycle’s electrical system.
Bump starting is also not recommended.
If you can’t charge the battery or it appears
unable to hold a charge, contact your Honda
dealer.
03/03/07 16:35:30 31KPS610_150

Honda CRF230F 2004 Specifications

General

Engine Type	223cc air-cooled single-cylinder four-stroke
Bore x Stroke	65.5mm x 66.2mm
Compression Ratio	9.0:1
Induction	22mm piston-valve carburetor
Ignition	CDI
Rear Brake	Drum
Front Tire	80/100-21
Rear Tire	100/100-18
Rake	26.7 degrees
Seat Height	34.1 inches
Ground Clearance	11.7 inches
Curb Weight	249 pounds
Front Suspension	37mm telescopic fork
Rear Suspension	Pro-Link single shock
Transmission	6-speed
