14 Instruments & Controls
Indicators & Displays
To adjust the Speed and Mileage Unit proceed as
follows:
1. Refer to Backlight Brightness Adjustment on
previous step.
2. Press SEL button to select either “mph” and
“mile” or “km/h” and “km”.
3. W
hen selecting the “mph” and “mile”
Press and hold SEL button. The speed and
mileage unit is set, and then the display will
return to the normal mode.
When selecting the “km/h” and “km”
Press and hold SEL button. The speed and
mileage unit is set, and then the display moves
the changing of the fuel mileage unit.
The established setting can also be set by stopping
the engine.
The control is automatically switched from the
setting mode to the normal mode if the button is
not pressed for about 30 seconds. Even in this case,
established setting is maintained.
If the “mph” for speed and “mile” for mileage are
selected, the fuel mileage unit cannot be select.
To adjust the Fuel Mileage Unit proceed as
follows:
1. Refer to Changing the Speed and Mileage Unit
on previous step.
2. Press SEL button to switch between “km/L” or
“L/100km”.
3. Press and hold SEL button. The fuel mileage
unit is set, and then the display will return to
the normal mode.
The established setting can also be set by stopping
the engine.
The control is automatically switched from the
setting mode to the normal mode if the button is
not pressed for about 30 seconds. Even in this case,
established setting is maintained.
Changing the Speed and Mileage Unit Changing the Fuel Mileage Unit
31MKE710.book14ページ２０１９年３月１１日 月曜日 午前１０時４７分

Honda CRF450X 2020 Specifications

General

Engine Type	449cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	12.0:1
Induction	Programmed Fuel Injection (PGM-FI), 46mm throttle body
Starter	Electric
Final Drive	Chain
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	110/100-18
Wheelbase	58.3 inches
Seat Height	37.6 inches
Fuel Capacity	2.0 gallons
Valve Train	Unicam, 4-valve
Ignition	Full transistorized
Rear Suspension	Pro-Link Showa single shock with spring preload, rebound and compression damping adjustability; 12.3 inches travel
Front Brake	Single 240mm disc
Curb Weight	275 pounds
Front Suspension	49mm leading-axle inverted telescopic Showa fork; adjustable compression and rebound damping; 12.0 inches of travel
