7
GENERAL DESCRIPTION
EC2200
(The illustrations in this presentation are based on the EC2200 model F, GV types)
[1] Fuel tank cap [12] Breaker combination
[2] Fuel tank [13] 230V/16A receptacles (blue) B, IT types
[3] Recoil starter grip [14] 230V/16A receptacles (black) F type,
[4] Fuel valve (blue) GV, IT types
[5] Choke lever [14’] 230V/10A receptacles (black) W type
[6] Earth braid [15] 115V/16A receptacles (yellow) B type)
[7] Spark plug cap [16] Engine oil drain plug
[8] Oil fiiller cap / dipstick [17] Engine switch
[8’] Oil filler cap (choice of [8] or [8’] as required) [18] Voltage selector switch 115/230V
[9] Air cleaner (B1 type)
[10] Label with list of specifications [19] “Serial number” Identification plate
[11] Muffler
B1
[18]
[2]
[17]
[10]
[9]
[11]
[14-14']
[13]
[15]
[16]
[8-8’]
[8-8’]
[12]
[1]
[3]
[4]
[7]
[6]
[5]
[19]
