STARTING SYSTEM
9-4
RECOIL STARTER REMOVAL/
INSTALLATION
BOLT
(6 x 10 mm) (3)
RECOIL STARTER
RECOIL STARTER GRIP
temporary knot
INSTALLATION:
Install the recoil starter rope in the position as shown.
RECOIL STARTER ROPE
REMOVAL:
Before removing the recoil starter grip, pull the
recoil starter grip and tie a temporary knot in
the middle of the recoil starter rope as shown.
INSTALLATION:
Tie a knot in the end of the starter rope as
shown.
10 mm
(0.4 in)
