STARTING SYSTEM
9-9
STARTER MOTOR REMOVAL/INSTALLATION (CXS TYPE ONLY)
Disconnect the starter motor wires and battery (+) cable from the starter motor.
Remove the fan cover (page 7-9).
STARTER MOTOR
BOLT (8 x 35 mm)
STARTER SOLENOID WIRE
BATTERY POSITIVE (+) CABLE
NUT (6 mm)
