SERVICE INFORMATION
2-10
FRAME/ENGINE CABLE/HARNESS ROUTING
CX TYPE
IGNITION
COIL
POWER COIL
OIL LEVEL SWITCH
CHARGE COIL
OIL ALERT UNIT
POWER COIL 2P
CONNECTOR
HARNESS CLIP
HARNESS CLIP
HOLD POSITION
GENERATOR
WIRE
HARNESS BAND
Terminal
number
Wire color
W
Y
Y
Bl
Bl
HARNESS BAND
Viewed from the generator side:
GENERATOR
WIRE
Terminal
number
Wire color
1Lg
2Gr
Terminal
number
Wire color
1Lg
2Gr
Main wire
harness side
Power coil side
Terminal
number
Wire color
G/W
Bl/W
Viewed from the lower side:
POWER COIL WIRE
GENERATOR
WIRE
IGNITION COIL
WIRE
FUEL CUT
SOLENOID
WIRE
HARNESS BAND
OIL ALERT UNIT
WIRE CONNECTOR
OIL LEVEL SWITCH
WIRE CONNECTOR
FUEL CUT
SOLENOID WIRE
CONNECTOR
FUEL CUT
SOLENOID WIRE
CONNECTOR
OIL ALERT UNIT
WIRE CONNECTOR
IGNITION
COIL WIRE
CONNECTOR
Bl Black Br Brown
Y Yellow O Orange
Bu Blue Lb Light blue
G Green Lg Light green
R Red P Pink
W White Gr Gray
GENERATOR
WIRE
FUEL CUT/CHARGE COIL
WIRE CONNECTOR
