SERVICE INFORMATION
2-11
CXS TYPE
IGNITION
COIL
STARTER
SOLENOID
FUEL CUT/
CHARGE
COIL
OIL ALERT UNIT
OIL LEVEL SWITCH
STARTER
SOLENOID
STARTER
MOTOR
HARNESS BAND
GENERATOR
WIRE
HARNESS BANDS
Terminal
number
Wire color
1Lg
2Gr
Terminal
number
Wire color
1Lg
2Gr
Main wire
harness side
Power coil side
HARNESS BAND
HOLD POSITION
HARNESS BAND
Viewed from the lower side:
POWER COIL WIRE
GENERATOR
WIRE
FUEL CUT
SOLENOID
WIRE
HARNESS BAND
BATTERY CABLE
Viewed from the upper side:
Do not secure the starter
cable at harness band
OIL ALERT UNIT
WIRE CONNECTOR
OIL LEVEL SWITCH
WIRE CONNECTOR
FUEL CUT/CHARGE COIL
WIRE CONNECTOR
GENERATOR
WIRE
Viewed from the generator side:
GENERATOR
WIRE
FUEL CUT
SOLENOID WIRE
CONNECTOR
FUEL CUT
SOLENOID WIRE
CONNECTOR
POWER COIL 2P
CONNECTOR
IGNITION COIL WIRE
CONNECTOR
OIL ALERT UNIT
WIRE CONNECTOR
Terminal
number
Wire color
G/W
Bl/W
Terminal
number
Wire color
W
Y
Y
Bl
Bl
Bl Black Br Brown
Y Yellow O Orange
Bu Blue Lb Light blue
G Green Lg Light green
R Red P Pink
W White Gr Gray
HARNESS BAND
