Honda EG6500CXS Owner's Manual

13
PRE-OPERATION CHECK
3.AIR CLEANER
1.Remove the air cleaner cover taking care not to damage it.
(1)Unsnap the air cleaner cover clips and pull the air cleaner cover.
(2)Free the hooks from the setting pins.
(3)Remove to the right side of the frame pipe.
2.Check the air cleaner element to be sure it is clean and in good
condition. Clean or replace the air cleaner element if necessary (see
page 30).
HOOK
SETTING PIN
AIR CLEANER COVER
AIR CLEANER ELEMENT
FRAME PIPE
CLIP
4MZ306030.book Page 13 Wednesday, January 13, 2016 11:37 AM

Honda EG6500CXS Specifications

General

AC Output	120/240V
Displacement	389 cc
Engine	Honda GX390
Rated Power	5.5 kVA
Maximum Power	6.5 kVA
DC Output	12V
Starting System	Electric
