68
TECHNICAL & CONSUMER INFORMATION
Tuneup Specifications
ITEM SPECIFICATION MAINTENANCE
Dimensions
Engine
Generator
Specifications
Spark plug gap
Valve clearance (cold)
Other specifications No other adjustments needed.
IN: 0.15 0.04 mm
EX: 0.20 0.04 mm
0.024 0.028 in
(0.6 0.7 mm)
Refer to page 50
See your authorized
Honda dealer.
Model
Description code
Length
Width
Height
Dry mass [weight]
Model
Engine type
Displacement
Bore Stroke
Compression ratio
Engine speed
Cooling system
Ignition system
Oil capacity
Fuel tank capacity
Spark plug
Model
Type
Rated voltage
Rated frequency
AC output Rated current
Rated output
Maximum output 2.0 kVA
1.6 kVA
13.3 A
60 Hz
120 V
CR5HSB (NGK)
0.95 US gal (3.6 L)
0.42 US qt (0.40 L)
Full transistor
Forced air
8.5:1
6.01 cu-in (98.5 cm
)
GX100
45.9 lbs (20.8 kg)
16.7 in (425 mm)
11.4 in (290 mm)
20.2 in (512 mm)
EAAJ
2.20 1.57 in (56.0 40.0 mm)
EU2000i Companion
EU2000i Companion
Californiatype(AC1type)
Non-California type (AN1 type)
4-stroke, overhead camshaft, single cylinder
Specifications may vary according to the types, and are subject to
change without notice.
4,300 5,000 rpm (with Eco-Throttle switch OFF)
