39
Clutch oil inspection
Recommended oil:
UPPER LIMIT
60 mm (2.4 in)
OIL LEVEL CHECK BOLT OIL LEVEL CHECK BOLT
BLOCK
TINE
Add the recommended oil if the level is low.
Stop the engine and set the tiller
on a firm level ground with the
rear wheels and tines.
Placea60mm(2.4in)thickblock
under the rear wheels as shown.
Remove the oil level check bolt
and check that the oil is level with
the lower edge of the oil level
check hole.
Use SAE 0W-20 Honda 4-stroke oil or SAE 0W-20 4-stroke motor oil
that meets the requirements for API service classification SL or
equivalent. Always check the API service label on the oil container to
be sure it includes the letters SL or equivalent.
Reinstall the check bolt and tighten it securely.
3.
1.
2.
4.
5.
