Honda Goldwing GL1800 2019 User Manual

165
continued
Maintenance
Removing & Installing Body Components
Battery
❙
Removal
Make sure the ignition switch is turned to
(Off).
After turning the ignition switch to (Off),
wait more than 60 seconds and then
remove the negative cable of the battery.
Because the electrical system may not
function correctly.
1. Remove the left side cover. 2 P. 168
2. Disconnect the negative - terminal
from the battery.
3. Disconnect the positive + terminal from
the battery.
4. Remove the battery holder bolt.
5. Swing the battery holder as shown to
avoid interference against the seat.
6. Remove the battery holder from the
hook.
7. Remove the battery taking care not to
drop the terminal nuts.
Positive + terminal
GL1800/B
Negative - terminal
GL1800BD/DA
Positive + terminal
Negative - terminal
Battery holder bolt
Battery holder
Battery holder
Hook
20 GL1800 32MKC820.book 165 ページ ２０１９年９月２０日 金曜日 午後３時９分

Honda Goldwing GL1800 2019 Specifications

General

Compression Ratio	10.5:1
Fuel System	Programmed Fuel Injection (PGM-FI)
Transmission	6-speed manual
Final Drive	Shaft
Front Tire	130/70R-18
Rear Tire Option 1	200/55R-16
Wheelbase	66.7 inches
Seat Height	29.3 inches
ABS	Standard
Bore x Stroke	73mm x 73mm
Transmission Option	7-speed automatic DCT
Front Suspension	Double-wishbone
Rear Suspension	Pro-Link single shock
Front Brakes	Dual 320mm discs
Rear Brakes	Single 316mm disc
Fuel Capacity	5.5 gallons
Curb Weight	379kg (835 lbs)
