Honda GXV340 - Muffler Protector; Spark Arrester; Identification Plate

25
MUFFLER PROTECTOR
5 mm SCREW
8mmBOLT
SPARK
ARRESTER
8 mm NUT
GASKET
MUFFLER
IDENTIFICATION PLATE
GXV390 only
Check for carbon deposits around the exhaust port and the spark
arrester, and clean if necessary.
The spark arrester must be free of breaks and holes. Replace, if
necessary.
Install the spark arrester and the muffler in the reverse order of
disassembly.
5.
4.
