Tire Puncture u Removing Wheels
106
Troubleshooting
Installation
1. Attach the side collars to the wheel.
2. On the left side, place the wheel
between the fork legs and insert the
lightly greased front axle shaft to the
end, through the left fork leg and wheel
hub.
3. Align the end of the front axle shaft with
the surface of the fork leg.
4. Tighten the left axle pinch bolt to hold
the axle.
5. Tighten the axle bolt.
6. Loosen the left axle pinch bolt.
7. Tighten the right axle pinch bolt.
8. Install the right brake caliper and tighten
new mounting bolts.
End of front axle
shaft
Surface of fork
leg
Torque: 44 lbf·ft (59 N·m, 6.0 kgf·m).
Torque: 16 lbf·ft (22 N·m, 2.2 kgf·m).
Torque: 33 lbf·ft (45 N·m, 4.6 kgf·m).
