Removing & Installing Body Components u Clip A
70
Maintenance
Clip A
The clip A must be removed to remove the
under cowl and radiator grill.
❙
Removal
1. Press down on the center pin to release
the lock.
2. Pull the clip out of the hole.
❙
Installation
1. Push the bottom of the center pin.
2. Insert the clip into the hole.
3. Press down on the center pin to lock the
clip.
Clip B
The clip B must be removed to remove the
under cowl.
❙
Removal
1. Remove the pin by a Phillips screwdriver.
2. Pull the clip out of the hole.
❙
Installation
1. Insert the clip into the hole.
2. Push the pin in.
Center
pin
!a !b
!a !b
