Removing & Installing Body Components u Single Seat Cowl
68
8.
Install the single seat cowl in the same
procedures of the rear seat installation.
2
P. 65
Make sure that the single seat cowl is locked
securely in position to pull it up lightly.
The seat locks automatically when closed.
Take care not to lock your key in the
compartment under the single seat cowl.
❙
Removal of Single Seat Cowl
Removal can be done in the reverse order of
installation.
u Tighten the grab rail mounting bolts.
Always reinstall the grab rails when
reinstalling the rear seat.
If a torque wrench was not used for
installation, see your dealer as soon as
possible to verify proper assembly. The grab
rail could come off easily and result in serious
injury if not assembled properly.
Ignition key
Seat lock
Single seat cowl
Prongs
Rear stays
Torque: 20 lbf·ft (27 N·m, 2.8 kgf·m).
