FUEL SYSTEM
3. Make sure the connection is secure and that the
pawls are firmly locked into place; check visually and
by pulling the fuel feed hose [1].
4. Make sure the joint rubber [2] is in place (between
the retainer tabs).
5. Increase the fuel pressure and check that there is no
leakage in fuel supply system (page 7-6).
FUEL PRESSURE NORMALIZATION
1. Connect the fuel pump 1P (Black) connector [1].
Connect the battery negative (–) cable (page 21-6).
2. Turn the ignition switch ON and engine stop switch
"".
• Do not start the engine.
The fuel pump will run for about 2 seconds, and fuel
pressure will rise.
3. Repeat 2 or 3 times, and check that there is no
leakage in the fuel supply system.
4. Turn the ignition switch OFF.
Install the following:
– Shroud/side cover (NC700X/XA/XD) (page 2-14)
– Shelter/side cover (NC700S/SA/SD) (page 2-15)
