FRONT WHEEL/SUSPENSION/STEERING
CLUTCH LEVER (NC700X/XA/S/SA)
REMOVAL/INSTALLATION
Remove the clutch lever pivot nut [1] and bolt [2].
Remove the clutch lever [3] and disconnect the clutch
cable [4].
Connect the clutch cable [1] to the clutch lever [2].
Install the clutch lever to the clutch lever bracket.
Apply grease to the clutch lever pivot bolt sliding
surface.
Install and tighten the clutch lever pivot bolt to the
specified torque.
Install and tighten the clutch lever pivot nut to the
specified torque while holding the clutch lever pivot bolt.
[1] [3]
[2]
[4]
TORQUE:1.0 N·m (0.1 kgf·m, 0.7 lbf·ft)
TORQUE:6.0 N·m (0.6 kgf·m, 4.4 lbf·ft)
[1] [2]
