Honda NC750X 2018 User Manual

Brakes
Checking Brake Fluid
1. Place your motorcycle in an upright
position on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
is horizontal and that the fluid level is
above the LOWER level mark.
Rear
Check that the brake fluid reservoir
is horizontal and that the fluid level is
between the LOWER level and UPPER
level marks.
If the brake fluid level in either reservoir is
below the LOWER level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear.
If the brake pads are not worn, you most
likely have a leak. Have your motorcycle
inspected by your dealer.
20180125134256_31MKL6000_enu_BOOK Page 114 Thursday, January 25 2018 13:52:25 JST
Maintenance
111
Front brake fluid reservoir
LOWER
level mark
UPPER level
mark
LOWER level
mark
Rear brake fluid reservoir
Front Rear

Honda NC750X 2018 Specifications

General

Bore x Stroke	77 mm x 80 mm
Compression Ratio	10.7:1
Fuel System	PGM-FI electronic fuel injection
Ignition	Digital transistorized with electronic advance
Final Drive	Chain
Front Tire	120/70ZR-17
Rear Tire	160/60ZR-17
Seat Height	32.7 inches
Fuel Capacity	3.7 gallons
Engine Type	Liquid-cooled, parallel-twin
Horsepower	54 hp
Max Power Output	54 hp (40.3 kW) @ 6, 250 rpm
Torque	50.1 lb-ft (68 Nm) @ 4, 750 rpm
Transmission	6-speed manual
Front Suspension	41 mm telescopic fork; 5.4 inches travel
Rear Suspension	Pro-Link single shock
Front Brake	320mm single disc with two-piston caliper
Rear Brake	240mm single disc with single-piston caliper
