Honda NC750XA User Manual

Safety Guidelines
5
Motorcycle Safety
check the tightness of critical nuts and bolts,
and check the handlebar, control levers, brakes,
and wheels. Ride slowly and cautiously.
Your motorcycle may have suffered damage
that is not immediately apparent. Have your
motorcycle thoroughly checked at a qualified
service facility as soon as possible.
Exhaust contains poisonous carbon monoxide,
a colourless, odorless gas. Breathing carbon
monoxide can cause loss of consciousness and
may lead to death.
If you run the engine in confined or even partly
enclosed area, the air you breathe could contain
a dangerous amount of carbon monoxide.
Never run your motorcycle inside a garage or
other enclosure.
Carbon Monoxide Hazard
3 WARNING
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill you.
Avoid any areas or activities that
expose you to carbon monoxide.
16 NC750XA XD-42MKA8000.book 5 ページ ２０１５年９月１６日 水曜日 午後１２時３９分

Honda NC750XA Specifications

General

Engine Displacement	745 cc
Compression Ratio	10.7:1
Fuel System	PGM-FI electronic fuel injection
Final Drive	Chain
Front Tyre	120/70ZR17M/C (58W)
Rear Tyre	160/60ZR17M/C (69W)
Width	845 mm
Starter	Electric
Engine Type	Liquid-cooled 4-stroke 8-valve SOHC parallel 2-cylinder
Bore x Stroke	77 mm x 80 mm
Max. Torque	68 Nm @ 4, 750 rpm
Fuel Tank Capacity	14.1 liters
Transmission Type	6-speed Manual / 6-speed DCT
Front Suspension	41 mm telescopic fork
Front Brake	Single 320 mm disc
Rear Brake	Single 240 mm disc
Seat Height	800mm
Curb Weight	220 kg
Max. Power	54.8 hp (40.9 kW) @ 6, 250 rpm
Rear Suspension	Pro-Link monoshock damper, with spring preload adjustment
