Servicing Your Honda
108
Center Rear Panel Removal
Refer to Safety Precautions on page 91.
The center rear panel must be removed for spark plug maintenance,
to change the engine oil filter, to clean the air cleaner.
Removal
1.
Remove the seat back (page 107).
2.
Release the prongs from their grommets.
3.
Pull the center rear panel forward.
Installation
1.
Insert the tabs into the holes.
2.
Install the prongs into their grommets.
3.
Install the center rear panel.
tab
holes
tabs
center rear panel
prongs
grommets
19 SXS500M-31HL56400.book 108 ページ ２０１８年７月３１日 火曜日 午後６時６分
