14
25 mm
(1 inch)
WT20X: C type
FUEL TANK TOP
FUEL TANK CAP
FUEL TANK CAP
FUEL TANK TOP
MAXIMUM FUEL LEVEL
FUEL TANK TOP
MAXIMUM FUEL LEVEL
WT20X: DE and UD types
WT30X · WT40X: DE, C and UD types
With strainer
(WT20X optional
part)
With the engine stopped and on a level surface, remove the fuel tank
cap and check the fuel level.
Refill the tank if the fuel level is low.
Do not fill the fuel tank completely. Fill tank to approximately 25 mm (1
inch) below the top of the fuel tank to allow for fuel expansion. If may
be necessary to lower the fuel level depending on operating
conditions.
After refueling, make sure the tank cap is closed properly and securely.
