Sediment cup cleaning
Gasoline is extremely flammable and is explosive under certain
conditions. Do not smoke or allow flames or sparks in the area.
3.
FILTER
(Viewed from the b ottom)
FILTER
O-RING
SEDIMENT CUP
FUEL VALVE LEVER
O
F
F
Align
Move the fuel valve lever to the OFF position, then remove the fuel
sediment cup, O-ring and filter.
Wash the sediment cup and filter in non-flammable solvent, and dry
it thoroughly.
Move the fuel valve lever to the ON position, and check for leaks.
Replace the O-ring if there is any leakage.
Place the filter and O-ring in the fuel valve, and install the sediment
cup. Tighten the sediment cup securely.
4.
1.
2.
3.
