35
5 mm SCRE WS
SPARK ARRESTER
MUFFLER PROTECTOR
4 mm SCREW
SPARK ARRESTER
[WT40X Type only]
MUFFLER
4 mm SCRE WS
5 mm SCRE WS
WT30X·WT40X
Remove the six 5 mm screws from the muffler protector, and
remove the muffler protector.
Remove the 4 mm screw from the spark arrester, and remove the
spark arrester from the muffler.
1.
2.
