Honda XR125L User Manual

××
−
−
−
−
−−
±
Bore and stroke
Compression ratio
Displacement
Spark plug
Standard
For extended high speed riding
Sparkpluggap
Valve clearance Intake:
Exhaust:
Idle speed
ENGINE
106
56.5 49.5 mm (2.22 1.95 in)
9.5 : 1
124 cm
(7.6 cu-in)
DPR8EA 9 (NGK)
X24EPR U9 (DENSO)
DPR9EA 9 (NGK)
X27EPR U9 (DENSO)
0.8 0.9 mm (0.03 0.04 in)
0.08 mm (0.003 in)
0.08 mm (0.003 in)
1,400 100 min
(rpm)
or
or
10/03/11 17:17:51 32KRHA00_116

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
