Honeywell Home HM750 User Manual

HM750A1000
33-00289EF—03 8
Steam Line Installation Examples
Fig. 9. Steam distributor above humidifier (hose).
Measurements in inches (mm).
Fig. 10. Steam distributor below humidifier with
obstruction (hose). Measurements in inches (mm).
Fig. 11. Common steam line installation errors.
M37200
12 (305)
MINIMUM
RADIUS
SUPPORT
BRACKETS
12 (305)
4 (102)
MINIMUM
HM750
Status
Service
Power
Idle
Filling
Humidifying
Draining
Cylinder
Fault
Drain
Fault Codes In Front Cover
CONNECT
STEAM
HOSE TO
CYLINDER
M37204
TO DRAIN
OBSTRUCTION
12 (305)
MINIMUM
RADIUS
SUPPORT
BRACKETS
USE FULL SIZE CONDENSATE
TEE AT LOW POINT. SLOPE
LINES UP TO “T” AND
IMMEDIATELY AFTER IT.
HOSE WILL SOFTEN OVER TIME. PROPER SUPPORT IS NECESSARY.
1
4 (102)
MINIMUM
12
(305)
MINIMUM
1
HM750
Status
Service
Power
Idle
Filling
Humidifying
Draining
Cylinder
Fault
Drain
Fault Codes In Front Cover
12 (305)
MINIMUM
M37205
NO
CONDENSATE
TRAP AT
VERTICAL
TRANSITION
STEAM LINE
NOT SLOPED
HM750
Status
Service
Power
Idle
Filling
Humidifying
Draining
Cylinder
Fault
Drain
Fault Codes In Front Cover
INSUFFICIENT
BEND RADIUS
INSUFFICIENT
BEND RADIUS
