3
LED INDICATIONS
Rapid Flashes for
about 20 seconds, then
ON for 3 seconds
Power Up – Enrollment
Slow Flashes
Power Up – Device enrolled; front Cover Tamper activated. To stop
flashes, clear the tamper condition by reattaching the cover. It also times
out after 10 minutes.
ON
(while in Programming Mode)
Sensor LED toggles on and off when the sensor is selected. See Sensor
Location Feature.
BATTERY REPLACEMENT
• Push the bottom latch of the mounting
bracket back to disengage it. Then slide
the back housing, up and out to remove
it from the mounting bracket.
• Slide the front and back housings in
opposite directions and pull the housings
apart.
• Remove the battery, wait 10 seconds,
then insert a new battery.
Recommended batteries:
Resideo 466
Duracell DL123A
Huiderui CR123A
Panasonic CR123A
• Place the front and back housings
together and slide them together as
shown.
BATTERY CAUTION: Risk of fire, explosion
and burns. Do not recharge, disassemble, heat
above 212°F (100°C) or incinerate. Dispose of
used batteries properly. Keep away from
children.
NOTE: Constant exposure to high or low
temperature or high humidity may reduce
battery life.
WARNING: Use only batteries specified in marking. Use of a different battery
may have a detrimental effect on product operation.
SPECIFICATIONS:
Battery: .................................. 1 x 3V Lithium, Resideo 466, Panasonic CR123A,
Duracell DL123A or Huiderui CR123A
Tamper: ............................................................................... Front Cover and Wall
RF Frequency: ........................................................................................... 2.4GHz
Operating Temperature: ................................................32° – 122° F / 0° – 50° C
(Agency Compliance 32° – 120° F / 0° – 49° C)
Relative Humidity: ......................... 95% max. (Agency Compliance - 93% max.),
non-condensing
Dimensions: ....... 1” H x 3.13” L x 1.61” W / 25.5 mm H x 79.5 mm L x 41 mm W
APPROVAL LISTINGS:
FCC / IC
cETLus Listed
Conforms to ANSI/UL 2017
Certified to CAN/CSA STD C22.2
#205
Other Standards:
RoHS
Product must be tested at
least once each year
