Honeywell 1080P - System Diagram and Dimensions; System Diagram; Dimensions

SYSTEM DIAGRAM AND DIMENSIONS
System Diagram
Monitor
Monitor
Monitor
Hybrid DVR
NVR
NETWORK
Keyboard
HDZ
tAnalogue ou
Dimensions
HDZ SERIES – 1080P HD IP PTZ DOMES
Outdoor Pendant
Using In-Ceiling Bracket
Indoor Pendant
123.00 mm
136.00 mm
155.89 mm
231.46 mm
190.00 mm
Ø254.00
123.00 mm
136.00 mm
155.89 mm
231.46 mm
190.00 mm
Ø254.00
Ø193.96
Ø192.00
