IMMERSION WELLS AND COMPRESSION FITTINGS
68-0040—04 4
Table 1. Copper Immersion Wells.
Table 2. Stainless Steel, Mild Steel, and Monel Immersion Wells.
Spud in
in. x 14
NPT
Shell ID/
Bulb
Diameter
Insertion/
Max Bulb
Length
Insulation
Depth
Capillary
Diameter
Includes
Part
Number
1/2 3/8 3 1-1/2 5/64 121371 Mounting Clamp 121371A
— — 123869A
Spud setscrew for armored capillary, plug 123732AA
3 5/64 121371 Mounting Clamp 121371L
3-1/2 1-1/2 121371 Mounting Clamp 121371P
3-3/4 1-1/2 1/8 112721 Spring Clip 112620AA
— Plastic sleeve on well tube 123869B
1/2 4-1/4 1-1/2 1/8 112721 Spring Clip 112622AA
4-1/4 4-1/2 112721 Spring Clip 112626AA
3/4 3/8 3 1-1/2 5/64 121371 Mounting Clamp 121371B
— — 123870A
3 5/64 121371 Mounting Clamp 121371M
121371 Mounting Clamp, plastic sleeve 123171N
— — 123871A
Plastic sleeve on well tube 123871B
4-1/2 — — 122555D
Plastic sleeve on well tube 122555A
3-1/2 1-1/2 5/64 121371 Mounting Clamp 121371Q
2-1/4 — — 138134B
4-1/2 Plastic sleeve on well tube 122555B
— 122555C
3/8 + 5/8 3 2-1/4 Plastic sleeve on well tube 138134E
4-1/2 122555E
1/2 4-1/4 1-1/2 1/8 112721 Spring Clip 112630AA
4 112634AA
8-1/4 1-1/2 112630AB
Spud in
in. x 14
NPT
Shell ID/
Bulb
Diameter
Insertion/
Max Bulb
Length
Insulation
Depth
Capillary
Diameter
Material Includes Part Number
1/2 3/8 3 1-1/2 5/64 Stainless
steel
121371 Mounting Clamp 121371E
1/2 4-1/4 1 1/8 Mild steel 112721 Spring Clip 112623AA
Stainless
steel
112721 Spring Clip 112624AA
4 1/8 Stainless
steel
112721 Spring Clip 112628AA
1 1/8 Stainless
steel
112721 Spring Clip 112632AA
