Honeywell 4600g Quick Start

Trigger
The following bar codes will allow you to use the reader in Manual
Trigger mode (need to press the trigger to read) or Presentation
mode (the reader is activated when it “sees” a bar code).
Streaming Presentation™
Note: Streaming Presentation Mode applies only to units with the
Advanced Illumination feature. Units with the advanced
illumination feature have a software revision of 31205480-118
or newer.
When in Streaming Presentation mode, the imager leaves the scan
illumination on all the time and continuously searches for bar codes.
Manual Trigger
(Default)
Presentation Mode
Streaming Presentation Mode

Honeywell 4600g Specifications

General

Wavelength	617 nm
Tilt angle range	27 - 42 °
Decoding standards	1D, 2D
Optical sensor resolution	752 pixels
Dimensions (WxDxH)	81 x 135 x 157 mm
Standard interfaces	USB, RS-232, Keyboard wedge, RS-485
Input voltage	4 - 14 V
Power consumption	382 mA
Certification	FCC Part 15, ICES-003, EN55022 Class A, ROHS, CE, UL
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	184 g
