Fire Alarm Control Panel IQ8Control C / M
92 FB 798951.10.GB0 / 04.15
Inhibiting MFAB activation
The master box or master box relay will not be activated if,
 the cover contact is open. Factory setting of solder jumper on module: BR2 = open ; BR3 = closed. The
customer data of the FACP must be programmed under menu point Functional designation of the MFAB
control module to suppress the activation of the master box when the cover contact is open.
 the operating panel keyboard has been enabled for operation (key-operated switch).
 the master box is disconnected.
 there is trouble with the master box.
Activation of the MFAB in dependency on the cover contact (BR2 and BR3)
The hardware adjustment of the activation of the MFAB is determined by the two solder bridges BR2 and BR3 on
the MB control module.
Factory setting Germany
D
configuration
BR2 = open
BR3 = closed
The activation of the MFAB occurs in dependency on the customer data
programming. If, for BR3 = closed example, activation has been suppressed in the
menu point Functional designation of the MFAB control module when the cover
contact is open, the master box will not be activated in the case of an event when
the cover contact is open.
Configuration for the Netherlands
NL
BR2 = closed
BR3 = open
The activation of the MFAB occurs independently of the customer data
programming. If, for example, activation has been suppressed in the menu point
Functional designation of the MFAB control module when the cover contact is
open, the master box will still be activated in the case of an event by hardware
when the cover contact is open.
9.1.1 Technical Data Master box activation module (Part No. 784385)
Operating voltage : Internal via the power supply module, + 5 V DC / +12 V DC
Quiescent current consumption : approx. 10 mA @ 12 V DC (without monitoring)
approx. 15 mA @ 12 V DC (monitored)
Emergency operation : yes
Fuses : Multifuse 1 A
Relay K1 :
1 monitored change-over contact (e.g. MFAB activation)
contact rating max. 30 V DC / 1 A
Monitored resistance 50 to 1000 Ω
Activation time (relay K1) Continuously or pulsed (0,25 s / 1,5 s / 2,5 s or 6 s)
Output "MFAB reset“ : max. 300 mA (+12 V DC or +24 V DC), short-circuit proof
Output "FDKB unlock" : max. 300 mA short-circuit proof
Compatibility : The Interface modules may be operated on a free selectable
micro module slot of the FACP IQ8Control.
For FACP 800x the MB interface module may be used as a
replacement devices.
