Honeywell HC35WZ2R25 User Manual

6
5
7
S5
E
l
e
c
t
r
i
c
a
l
T
a
p
e
POE+
1
2
3
4
5
6
1 Network RJ45
2 Power
Red
AC 24V
Black
AC 24V
Yellow Green
GND EARTH
3 Audio Out
Red
Audio OUT
Grey Black
Audio GND
4 Audio In
White
Audio IN
Yellow Black
Audio GND
5 Alarm In
Purple
Alarm IN 1
Grey
Alarm IN COM
Yellow
Alarm IN 2
6 Alarm Out
White
Alarm OUT 1
White Black
Alarm OUT 1 COM
Orange
Alarm OUT 2
Orange Black
Alarm OUT 2 COM
AC24V 3A
Adaptor
OR
8
POE+
AC24V 3A
Adaptor
OR

Honeywell HC35WZ2R25 Specifications

General

Brand	Honeywell
Model	HC35WZ2R25
Category	Security Camera
Language	English
