HE220 AND HE260 BY-PASS FLOW-THROUGH HUMIDIFIER
3 69-1111EF—05
Required Accessories (Included)
Table 1. Required Accessories
Quantity Accessory Illustration
3 ft (0.93m) Bypass ducting including:
• 6 in. (155 mm) diameter flexible
duct
• Starter collar (flanged)/Summer
shut-off damper
• Plain collar
• Connecting straps (2)
20 ft (6.2m) 18 gauge, two-strand thermostat
wire
20 ft (6.2m)
10 ft (3.1m)
1/4 in. (6.35 mm) OD feed water
tubing
1/2 in (12.7 mm) ID drain tubing
1 bag Connecting and mounting hardware:
• Wire nuts (4)
• No. 8 sheet metal screws (18)
• Drain tube clamp
• Feed tube mounting clamps (6)
• Brass inserts (2)
• Plastic compression rings (2)
M31002
FLEXIBLE DUCT
M31001
PLAIN COLLAR
M31019
STARTER COLLAR/
DAMPER
M31077
CONNECTING
STRAP
THERMOSTAT WIRE
M31006
M31007
PLASTIC TUBING
M31009
WIRENUT
M31014
DRAIN TUBE CLAMP
M31015
SHEET METAL SCREW
#8
M31020
CLAMP
