SERIES 90 MODUTROL IV™ MOTORS
3 63-2631
Fig. 1. Modutrol IV Motor mounting dimensions in inches (mm).
Table 2. Series 90 Modutrol Motor
Power Consumption Ratings.
Table 3. Auxiliary Switch Ratings (in Amps).
a
40 VA pilot duty, 120/240 Vac on opposite contact.
Timing And Torque: See Table 4.
Approvals:
Underwriters Laboratories Inc. Listed: File No. E4436, Guide
No. XAPX.
Canadian Standards Association Certified: General Listed File
No. LR1620, Guide 400-E.
U.S. Patents: pending
M18998
4-7/8
(124)
5-1/2
(140)
13/16
(20)
4-1/16 (103)
1/4
(7)
1-1/2 (37)
4-1/16 (103)
JUNCTION
BOX
MOTOR
AUXILARY
END
POWER
END
ADAPTER
BRACKET
2-9/16
(66)
5-3/8
(137)
6-7/16
(164)
9/16 (15)
3/4
(19)
TOP VIEW OF BRACKET TOP VIEW
4-5/8
(116)
4-1/4
(107)
2-5/16
(58)
11/16
(17)
4-7/8 (124)
5-9/16 (141)
1/4 (7)
5-13/16
(148)
1
POWER END
2
3
1-1/2 (37)
3/4
(19)
SPRING RETURN MODEL SHOWN
FOR HIGH TORQUE (60 LB-IN.) SPRING RETURN MODELS 8-3/4 (222).
FOR NON-SPRING RETUIRN MODELS 7-5/16 (185).
FOR HIGH TORQUE (60 LB-IN.) SPRING RETURN MODELS (SHOWN).
FOR NON-SPRING RETURN MODELS.
1
2
3
13/16
(20)
Internal
Transformer
Power Consumption
Non-Spring Return Motors
Spring Return
Motors
75, 150 and
300 lb-in.
Torque
35 lb-in.
Torque
60 lb-in.
Torque
(VA) (W) (VA) (W) (VA) (W)
No 14 12 18 16
Yes 16 14 20 18
Single Contact Rating
a
120 V 240 V
Full Load 7.2 3.6
Locked Rotor 43.2 21.6
