- 7 -
Camera Setting
1. Loosen the 8ea screws and then apart the Camera Housing cover out of the Camera Housing body.
Then the showing the above figure4.
2. See the figure5 for Setting of communication with the switch on the RX Board.
Rx Board(Receiver Board)
Figure4.
Rx Board out of Camera Housing
ENG
