BUILDING NETWORK ADAPTER BNA-1C/2CS/2DN
8 EN1B-0198GE51 R0801
2 Location of Parts and Controls
The numbering for the parts and controls in this
section is referring to the pictures on the rear side of
the title page. In order to have a reference between
the numbering here and the device pictures, it is
possible to fold this page out.
2.1 Front Side
Differences between the various BNA types are
explicitly noted in the concerning element
description.
1 Reset
Hardware reset button. Located directly behind
the small hole in the front panel. To reach this
button, a pointed object like a sharp pen or an
unfolded paper clip is necessary. Pressing this
button resets the BNA device immediately. This
operation is similar to power on the BNA
device.
2 Mode
Mode switch button. This button is needed to
change the bootloader modes. For a detailed
description about BNA operation modes, please
refer to chapter 6.2 Operating Modes on Page 25.
3 LAN
Local Area Network (LAN) activity display.
