S8600F,H,M; S8610F,H; S8660D; S8670D
4
VENT
GND 24V TH-W
DAMPER
MV MV/PV PV
(BURNER) GND
24V
(OPT)
PLUG (OPT) SPARK
PILOT COM
4
3
MAIN
1ST 2ND
VALVE
OPERATOR OPERATOR
DUAL VALVE COMBINATION
1K
GAS CONTROL
D80D
1K1
N.C.
N.O.
4
D80 MOTOR
C.
1K3
3
1K2
2 1
Q345, Q346,
Q348, Q362,
Q381PILOT
BURNER/
IGNITER-
SENSOR
PILOT
BURNER
GROUND
PILOT GAS
SUPPLY
CABLE
2
L1
(HOT)
1
BLUE
YELLOW
G
L1
5
BLACK
TP
1K
ORANGE
B R
L8148J
1K1
1K3
Z W T
TV
1K2
AUTO
MANUAL
SWITCH
C1
FAN
MOTOR
L2
L2
B3 B2 B1 C2
M1181C
THERMOSTAT
1 POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD PROTECTION AS REQUIRED.
2 CUT PLUG OFF MODULE END OF D80D WIRE HARNESS, CONNECT LEADWIRE COLORS AS SHOWN.
3 MAXIMUM CABLE LENGTH 3 ft [0.9 m].
4
FOR MODULE WITH TH-W TERMINAL AND VENT DAMPER PLUG, CONNECT THERMOSTAT TO TH-W.
LEAVE 24V OPEN. DO NOT REMOVE VENT DAMPER PLUG.
5 LEAVE TP-Z AND Z-W JUMPERS IN PLACE.
Fig. 9—S8600F,H,M; S8610F, H; S8660D; S8670D connections in a hydronic heating sytem with a
D80D vent damper.

Honeywell S8610F Specifications

General

Brand	Honeywell
Model	S8610F
Category	Control Unit
Language	English
