Chapter 8: Specifications
72
User Guide for ScanPal Series Terminal
8 Specifications
Mechanical and environmental specifications
This Chapter provids the physical and environment specifications of EDA70-X
Product dimensions
Length
214 mm
Width 118 mm
Thickness 21 mm
Weight (with battery) 550 g (with battery)
Tumble and drop standards
Tumble
200 impacts within 0.5m
Drop Multiple 1.2 m drops to concrete
Power and electrical specifications
Battery
Rechargeable Li-ion battery, 3.8 V, 4000mAh
Charging power 5 V, 1.2 A
Temperature and humidity specifications
Operating
temperature
-10 °C ～ 50 °C (14 °F ～ 122 °F)
Storage temperature -20 °C ～ 60 °C (-4 °F ～ 140 °F)
Relative humidity
(during operation)
10% to 90%, non condensing
Environmental
sealing
IP64
