T775A/B/M SERIES 2000 CONTROLLER 1. PROGRAMMING
62-0254–03 16
Fig. 32. Program - Setback.
1.2.5. SETBACK
The Setback temperature option displays if scheduling is
enabled (see Fig. 55 on page 24) or the DI Option is set to
Setback. (see Fig. 57 on page 25).
This is the desired setpoint temperature that you want to
use during setback mode for this output. For example, if
your setpoint is 70°F and you want the temperature to
drop 10°F during setback mode, enter 60°F as the set-
point for this output.
1. From the menu, use the S and T buttons to high-
light SETBACK.
2. Use the S and T buttons to increase/decrease the
desired setpoint temperature.
Default: 60°F (16°C)
Range: -40°F to 248°F (-40°C to 120°C)
3. Press the X button to accept the value and display
the menu.
1.2.6. Program Next Output (Mod or Relay)
For the next output (Mod or Relay), select the desired
output from the Program menu (see Fig. 26 on page 14).
Go to “1.2.1. SETPOINT” on page 14 to program the next
output.
When you finish programming the outputs, continue with
“1.2.7. Exiting Program Mode” on page 16.
Fig. 33. Program - Exit.
1.2.7. Exiting Program Mode
Press the HOME button to leave programming mode and
return to the home screen.
This completes the programming procedure.
ENTER
SETBACK
SETPOINT
FOR RELAY 1
PROGRAM
RELAY 1
SETBACK
MENU
PROGRAM
RELAY 1
SETBACK
60
F
o
M24498
MENU
PROGRAM
MOD 1
MOD 2
RELAY 1
RELAY 2
RELAY 3
RELAY 4
EXIT
M24499
