1.5.3 Input Cable 1 – Door Contact

The balanced input 1 is dedicated to door status control; the balancing

resistances must be positioned near the clean sensor contact.

White

Yellow

magnetic door contact

NC CONTACT

Figure 7: Connection for Balanced Input 1 – Door Contact

GND (black)

IN1 (green / white)
