Page 13 of 24
VEXT _+VDC
VEXT_GND
coil for electrical locking device/repeater
1N4004
Diode Transient
Suppresso
r
Relay 1
Figure 9: Connection for Output Relay 1 (NO) – Door Open – DC Voltage
VEXT_Vac1
VEXT _Vac2
Bobina elettroserratura / relè di ripetizione
Mov75Vac
Soppressore
di transienti
Rele 1
Figure 10: Connection for Output Relay 1 (NO) – Door Open – AC Voltage
Green = C
Yellow = NC
Gray = NO
Green = C
Yellow = NC
Gray = NO
